specification |
---|
colour | matt granite copper/grey
| cassette | sunrace csms8, 11-42, 11 speed
|
frame | 6061 alloy, hydro formed t6 aluminium, multi butted, scr, tapered head tube, custom drawn, chainstay flat mount 160mm disc mount, dox cable routing
| chain | sunrace cn11, black, 11 speed
|
fork | whyte straight bladed 6061 alloy, tapered alloy steerer, internal cable routing, flat mount dropouts, 12mm x 100mm stealth thru axle, eyelets for mudguards
| crankset | whyte, forged cranks, direct mount 44t narrow wide chainring, 11 speed
|
rear shock | n/a | bottom bracket | shimano bb-rs500, 68mm
|
headset | fsa no. 42, integrated road, 1 1/2" lower and 1 1/8" upper sealed cartridge bearings
| seatpost | whyte 6061 alloy, 20mm offset, 27.2mm x 350mm, 2 bolt clamp
|
rear hub | alloy, double sealed cartridge bearings, 12mm x 142mm thru axle, centre-lock, 32 hole, concealed hex key
| saddle | whyte custom, light weight triple density base, triple panel design
|
front hub | alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, centre-lock, 32 hole, concealed hex key
| handlebar | controltech, 6061 alloy, gravel/road compact drop, 10mm riser bar, 31.8mm x 440mm 50cm, 460mm 52&54cm, 480mm 56&58cm
|
spokes | dt swiss champion 2.0mm, black stainless, brass nipples
| stem | whyte alloy, +-7? Rise, 50cm 60mm, 52cm 70mm, 54cm 80mm, 56/58cm 90mm extension
|
rims | wtb st i25 tcs 2.0 system, pinned joint, tubeless ready, 32 hole
| grips | whyte anti slip, cross bar tape
|
tyre | maxxis, receptor tr, 650b x 47c, 120 tpi, exo tan sidewall protection
| brakes front | sram apex 1 hydraulic, centre-lock 180mm disc, flat mount, internal routing
|
shift levers | sram apex 1, full hydraulic, 11 speed
| brakes rear | sram apex 1 hydraulic, centre-lock 160mm disc, flat mount, internal routing
|
front mech | n/a | brake levers | sram apex 1, hydraulic
|
rear mech | sram apex 1, long cage, 11 speed
| pedals | none |
weight | tbc
| | |
